AC1200 Dual-Band Wi-Fi 5 VDSL2 HGW — ZXHN H168A

The ZXHN H168A is an incredible fast VDSL2 router delivering up to 1200 Mbps Wi-Fi and Gigabit Ethernet speeds. It provides a Gigabit Ethernet WAN/LAN port and three FE LAN ports, ideal for the deployment in FTTH scenarios.

Product Highlights

Multiple WAN Access
· Enhanced VDSL2 35b data with vectoring
· Configurable Gigabit Ethernet WAN/LAN port
Ultimate Wi-Fi Experience
· Dual-band concurrent Wi-Fi speed up to 1200 Mbps
· Supports multiple HD video streams effortlessly
Multiple USB Functions
· DLNA Digital Media Server (DMS)
· Data service backup via LTE/3G dongle
Robust Remote Management
· Complies with TR-069 remote management

Product Parameters

WAN
VDSL2/ADSL2+
LAN
1 x GE WAN/LAN
3 x FE RJ-45 ports
2 x 2 802.11n Wi-Fi @2.4GHz
2 x 2 802.11ac Wi-Fi @5GHz
1 x USB 2.0
Buttons
WPS, WLAN, Reset, On/Off
Power Supply
AC adapter: 12 VDC, 1.5A
LEDs
Power, DSL, Internet, 2.4GHz, 5GHz, WPS, USB
Dimensions (W x H x D)
210 x 32 x 140 mm
Operating Temperature
0℃ ~ +40℃
Humidity
5% - 95% (non-condensing)
Certification
CE, Wi-Fi
