BE19000 Tri-Band Wi-Fi 7 HGW — ZXHN H8748Q

The ZXHN H8748Q is a 10 Giga-Eth uplink residential gateway with an in-house chip to provide Wi-Fi 7 BE19000 capability and enable high-bandwidth video and gaming services. It also features advanced Quality of Service (QoS), security firewalls, and extensive remote management to deliver reliable and manageable home networks.

Product Highlights

10Giga-ETH WAN Port: · 10 GE WAN
· Provides high bandwidth and high throughput for IP networking

More Flexible Management: · TR-069 protocol remote management
· WEB GUI based remote and local management

Ultimate Wi-Fi 7 Experience: · Higher-order 4096-QAM modulation, up to 320MHz bandwidth bring better concurrency and higher efficiency
· Triple band Wi-Fi 7 speed up to 19000 Mbps, 320MHz @6GHz

Product Parameters

WAN: 10 GE RJ-45 port

LAN: 1 x 10GE RJ-45 port
3 x GE RJ-45 ports
2 x FXS RJ-11 ports
1 x USB 3.0
4 x 4 802.11b/g/n/ax/be Wi-Fi @2.4GHz
4 x 4 802.11a/n/ac/ax/be Wi-Fi @5GHz
4 x 4 802.11ax/be Wi-Fi @6GHz

Buttons: Wi-Fi, WPS, Reset

Power Supply: AC adapter: 12 VDC, 3.0A

LEDs: Internet, Phone, Wi-Fi

Dimensions (W x H x D): 227.8 x 215 x 60 mm

Operating Temperature: 0℃ ~ +40℃

Humidity: 5% - 95% (non-condensing)

Certification: CE, Wi-Fi 7 certification ready
