4K Combo STB — ZXV10 B866GV6H

The ZXV10 B866GV6H is an UHD STB media gateway integrating STB, home gateway and wireless routing functions. Based on the Android TV platform, the STB subsystem adopts advanced hardware and the AV1/HEVC (up to 4K x 2K @ 60fps) UHD video processor to offer rich services such as OTT video, online music and 3D games to end users. The routing subsystem adopts the Linux platform, has one 1000M WAN port and IEEE802.11ax 2.4G and 5G 2T2R Wi-Fi. It supports multi VLAN, and bridging, routing and multi-routing simultaneously.

Product Highlights

4K Combo STB
· Multifunctional three-in-one device (Gateway, Router, STB)
· 2*2 Wi-Fi 6
· WiFi Mesh

Product Parameters

Ethernet
1*GE WAN Port
1*GE LAN Port
Video
Up to 4Kx2K@60fps
Bluetooth
Built-in Bluetooth 5.0
HDMI
1 * HDMI 2.1 output with HDCP 2.3
USB
1 * USB 2.0 host port, Type A
Certification
CE, WiFi, HDMI
Power
Input: AC 100-240V, 50-60Hz, Output: DC 12V 1.5A
Dimensions & Weight
128 x 70 x 205 mm
500g
