AC1200 Dual-Band Wi-Fi 5 GPON ONT — ZXHN F670L

The ZXHN F670L is an AC1200 dual-band triple-play GPON gateway that provides four GE LAN ports and one phone port. It provides a dual-band concurrent Wi-Fi speed up to 1200 Mbps, allowing users to surf the internet, watch videos and play online games.

Product Highlights

More Flexible Management: · Complies with ITU-T G.988 OMCI
· Complies with TR-069 management

Ultimate Wi-Fi Experience: · Dual-band concurrent Wi-Fi speed up to 1.2 Gbps
· Band steering and smart roaming optimize QoS

High Reliability: · The highly reliable heat dissipation design guarantees its stable operation.
· The dual image ensures uninterrupted services during software download or upgrade, enhancing software reliability.

Product Parameters

WAN: GPON

LAN: 4 x GE RJ-45 ports
1 x FXS RJ-11 port
1 x USB 2.0 port
2 x 2 802.11b/g/n Wi-Fi @ 2.4 GHz
2 x 2 802.11a/n/ac Wi-Fi @ 5 GHz

Buttons: Wi-Fi, WPS, Reset, Power On/Off

Power Supply: AC adapter: 12 VDC, 1.0A

LEDs: Power, PON, LOS, Internet, LAN1, LAN2, LAN3, LAN4, Phone, Wi-Fi, WPS, USB

Dimensions (W x H x D): 210 x 130 x 35 mm

Operating Temperature: 0℃ ~ +40℃

Humidity: 5% - 95% (non-condensing)

Certification: CE, Wi-Fi
