BE15000 Tri-Band Wi-Fi 7 Mesh AP — ZXHN H6701Q

The ZXHN H6701Q is a 2.5GE uplink residential gateway, equipped with an in-house chip to provide Wi-Fi 7 BE15000 capability and enable high-bandwidth video and gaming services. The ZXHN H6701Q also features advanced Quality of Service (QoS), security firewalls, and extensive remote management to deliver a reliable and manageable home network.

Product Highlights

2.5 GE WAN Port
· 2.5 GE WAN
· Provides high bandwidth and high throughput for IP networking
More Flexible Management
· Complies with TR-069 remote management
· WEB GUI based remote and local management
Ultimate Wi-Fi 7 Experience
· Higher-order 4096-QAM modulation and up to 320 MHz bandwidth bring better concurrency and higher efficiency
· Triple-band Wi-Fi 7 speed up to 15000 Mbps and 320MHz @6GHz

Product Parameters

WAN
2.5 GE
LAN
1 x GE RJ-45 port
2 x 2 802.11b/g/n/ax/be Wi-Fi @2.4GHz
2 x 2 802.11a/n/ac/ax/be Wi-Fi @5GHz
4 x 4 802.11ax/be Wi-Fi @6GHz
Buttons
WPS, Reset, On/Off
Power Supply
AC adapter: 12 VDC, 2.0A
LEDs
Status
Dimensions (W x H x D)
182 x 154 x 62 mm
Operating Temperature
0℃ - 40℃
Humidity
5% - 95% (non-condensing)
Certification
CE, Wi-Fi 7, EasyMesh
