Product Overview
ZXV10 B866V2K
ZXV10 B866V2K is a UHD STB based on Android TV platform, the version of OS is Android TV R or greater. It adopts advanced hardware and AV1/HEVC (up to 4K*2K@60fps) UHD video processor. It supports Wi-Fi 5, which provides rich services including but not limited as OTT video, online music, 3D games to the end users.
Product Parameter
| Model | Parameter | |
|---|---|---|
| CPU | Quad core ARM Cortex-A35 | |
| GPU | ARM G31 MP2 GPU | |
| Video | AV1 MP-10@L5.1 up to 4Kx2K@60fps | |
| Size & Weight | 108 mm*108 mm*23 mm, 185g | |
| Memory | Flash: 8GB eMMC(optional for 16GB/32GB), RAM: 2GB DDR(optional for 4GB) | |
| Ethernet | 1*Ethernet 10/100M Base-T, RJ45 port | |
| Audio | MPEG1 Layer 1/2, MPEG1 Layer3, AAC | |
| Wi-Fi | IEEE 802.11 b/g/n/ac 2x2 MU-MIMO | |
| USB | 1*USB 2.0 host port, Type A | |
| AV | TRRS interface: output CVBS and L/R audio | |
| HDMI | 1*HDMI 2.0b output with HDCP 2.3 | |
| RCU | Infrared remote controller, NEC 38KHz；Bluetooth remote controller support | |
| OS | Android TV 11 | |
| DRM | Widevine L1, PlayReady3.0 | |
| Certification | CE, Dolby Digital Plus, HDMI | |
| Power | Input: AC 100-240V, 50-60Hz, Output: DC 12V 1A；Typical: <3.6W under typical working condition(without USB devices) | |
